10'' Cast Iron Deep Well Pump
  • 10'' Cast Iron Deep Well Pump10'' Cast Iron Deep Well Pump

10'' Cast Iron Deep Well Pump

Deep Well Compatibility: ZΞN 10'' Cast Iron Deep Well Pump is specially designed to work in deep wells and can easily produce water from significant depths.
The cast iron deep well pump is a water intake unit that combines a submersible motor and a submersible pump.
Direct integration into the kit, work in deep water. Mainly used for irrigation of agricultural land, water supply and sewerage of cities, industrial and mining enterprises.
Can be used to develop underground hot water below 100°C, with heat resistance, corrosion resistance, aging resistance and other characteristics.

Send Inquiry

Product Description

10'' Cast Iron Deep Well Pump

Features:

Flow: 2 - 1000 m3/h

Load: 10m - 1000m

Motor power: 0.55kW-600kW

Rated voltage: 380V/660V


primary goal


Description of the structure

1. The underwater electric pump is composed of five parts: water pump, motor, water line, waterproof cable and control switch. The pumps are single-suction multistage vertical centrifugal three-cylinder pumps.

2. The submersible motor uses YQS type water-filled wet design, filled with clean water in the cavity, mainly for cooling the motor and lubricating the bearings. During operation, since changes in temperature may cause changes in water filling, pressure regulators are installed in the engine for calibration.

3. To prevent sand from entering the motor, the upper motor is equipped with a sandproof sealing mechanism, consisting of a sand punch and a mechanical seal, which forms a sandproof structure, and the entire motor is well sealed through its sealed structure.

4. There are water injection holes and exhaust holes on the top of the engine, and drainage holes on the bottom.

5. The thrust bearings and thrust rings are installed at the bottom of the motor and mainly bear the axial force of the electric pump.

6. The motor stator winding uses waterproof electromagnetic line with good insulation and waterproof performance, the rotor uses mouse cage structure.

7. Stainless steel submersible pumps are used for corrosive water quality.


Electrical design


Pump design


Installation diagram


Performance curve


Type Explanation


Number

Model

Minimum well diameter (mm) QJ (flow rate (m3/h) - flow pressure (m)/impeller level

 Deep well pump Submarine electric motor Rotational speed outlet pipe diameter

Cable Specification Compliance

Maximum pump outer diameter
Height Weight Power Height Weight
(mm) (kg) (kW) (mm) (kg) (rpm) (")
(mm)
1 250QJ32-138/6 1125 110 22 981 143.6 2875 2.5 3×10 233
2 250QJ32-161/7 1260 125 25 1001 149.6 3×16
3 250QJ32-184/8 1395 140 30 1036 160.6 3×16
4 250QJ32-207/9 1530 155 37 1076 165.6 2875 2.5 3×25 233
5 250QJ32-230/10 1665 170 37 1076 165.6 3×25
6 250QJ32-253/11 1800 185 45 1141 170.6 3×35
7 250QJ32-276/12 1935 200 45 1141 170.6 3×50
8 250QJ32-300/13 2070 215 55 1644 200.6 3 3×50
9* 250QJ32-322/14 2205 230 55 1644 200.6 3×50
10* 250QJ32-345/15 2340 245 63 1889 241 3×70
11* 250QJ32-368/16 2475 260 63 1889 241 3×70
12* 250QJ32-391/17 2610 275 63 1889 241 3×95
13* 250QJ32-414/18 2880 290 75 2039 296 3×95
14* 250QJ32-437/19 3015 305 75 2039 296 3×95
15* 250QJ32-460/20 3150 320 75 2039 296 3×120
16* 250QJ32-483/21 3285 335 90 2159 310 3×120
17* 250QJ32-506/22 3420 350 90 2159 310 3×150
18* 250QJ32-529/23 3555 365 110 2349 345 3×185
19* 250QJ32-552/24 3690 380 110 2349 345 3×185
20* 250QJ32-575/25 3825 395 110 2349 345 3×185
21* 250QJ32-598/26 3960 410 110 2349 345 3×185
22* 250QJ32-621/27 4095 425 110 2349 345 3×240
23* 250QJ32-644/28 4230 440 110 2349 345 3×240
24* 250QJ32-667/29 4395 455 125 2561 597 3×240
25* 250QJ32-690/30 4500 470 125 2561 597 3×240
26* 250QJ32-713/31 4635 485 125 2561 597 3×240
27* 250QJ32-736/32 4770 500 140 2731 602 3×300
28* 250QJ32-759/33 4905 515 140 2731 602 3×300
29* 250QJ32-782/34 5040 530 140 2731 602 3×300
30* 250QJ32-805/35 5310 545 140 2731 602 3×400
31* 250QJ32-828/36 5445 560 160 2821 612 3×400
32* 250QJ32-851/37 5580 575 160 2821 612 3×400
33* 250QJ32-874/38 5714 590 160 2821 612 3×400
34* 250QJ32-897/39 5850 605 160 2821 612 3×400
35* 250QJ32-920/40 5985 620 160 2821 612 3×400
36 250QJ40-126/6 1125 117 25 1001 150.6 3×10
37 250QJ40-147/7 1260 135 30 1036 160.6 3×16
38 250QJ40-168/8 1395 153 37 1076 165.6 3×25
39 250QJ40-189/9 1530 171 37 1076 165.6 3×25
40 250QJ40-210/10 1665 189 45 1141 170.6 2875 3 3×35 233
41 250QJ40-231/11 1800 207 45 1141 170.6 3×35
42 250QJ40-252/12 1935 225 55 1216 180.6 3×50
43 250QJ40-273/13 2070 243 55 1216 180.6 3×50
44* 250QJ40-294/14 2205 261 63 1889 241 3×70
45* 250QJ40-315/15 2340 279 63 1889 241 3×70
46* 250QJ40-336/16 2475 297 75 2039 296 3×95
47* 250QJ40-357/17 2610 315 75 2039 296 3×95
48* 250QJ40-378/18 2880 333 75 2039 296 3×95
49* 250QJ40-399/19 3015 351 90 2159 310 3×120
50* 250QJ40-420/20 3150 369 90 2159 310 3×120
51* 250QJ40-441/21 3285 387 90 2159 310 3×120
52* 250QJ40-462/22 3420 405 110 2349 345 3×150
53* 250QJ40-483/23 3555 423 110 2349 345 3×185
54* 250QJ40-504/24 3690 441 110 2349 345 3×185
55* 250QJ40-525/25 3825 459 125 2561 597 3×185
56* 250QJ40-546/26 3960 477 125 2561 597 3×240
57* 250QJ40-567/27 4095 495 125 2561 597 3×240
58* 250QJ40-588/28 4230 513 140 2731 602 3×240
59* 250QJ40-609/29 4395 531 140 2731 602 3×240
60* 250QJ40-630/30 4500 549 140 2731 602 3×300
61* 250QJ40-651/31 4635 567 140 2731 602 3×300
62* 250QJ40-672/32 4770 585 160 2821 612 3×300
63* 250QJ40-693/33 4905 603 160 2821 612 3×400
64* 250QJ40-714/34 5040 621 160 2821 612 3×400
65* 250QJ40-735/35 5310 639 160 2821 612 3×400
66 250QJ50-20/1 316 33 5.5 690 70 3×4
67 250QJ50-40/2 476 48 9.2 750 79 3×4
68 250QJ50-60/3 636 63 13 780 87 3×6
69 250QJ50-80/4 994 88 18.5 961 135.6 3×6
70 250QJ50-100/5 1154 104 22 981 143.6 3×10
71 250QJ50-120/6 1314 119 25 1001 150.6 3×16
72 250QJ50-140/7 1474 135 30 1036 160.6 3×16
73 250QJ50-160/8 1634 150 37 1076 165.6 3×25
74 250QJ50-180/9 1794 166 45 1141 170.6 3×25
75 250QJ50-200/10 1954 181 45 1141 170.6 3×25
76 250QJ50-220/11 2114 197 55 1216 180.6 2875 3 3×35 233
77 250QJ50-240/12 2274 212 55 1216 180.6 3×50
78 250QJ50-260/13 2434 228 63 1461 231 3×50
79 250QJ50-280/14 2594 243 63 1461 231 3×50
80 250QJ50-300/15 2754 258 63 1461 231 3×70
81* 250QJ50-320/16 3074 273 75 2039 396 3×70
82* 250QJ50-340/17 3234 288 90 2159 310 3×95
83* 250QJ50-360/18 3394 303 90 2159 310 3×95
84* 250QJ50-380/19 3554 318 110 2349 396 3×120
85* 250QJ50-400/20 3714 333 110 2349 396 3×120
86* 250QJ50-420/21 3874 348 110 2349 396 4 3×150
87* 250QJ50-440/22 4034 363 110 2349 396 3×150
88* 250QJ50-460/23 4194 378 110 2349 396 3×150
89* 250QJ50-480/24 4354 393 125 2561 597 3×185
90* 250QJ50-500/25 4514 408 125 2561 597 3×185
91* 250QJ50-520/26 4674 423 125 2561 597 3×185
92* 250QJ50-540/27 4834 438 140 2731 602 3×240
93* 250QJ50-560/28 5154 453 140 2731 602 3×240
94* 250QJ50-580/29 5314 468 140 2731 602 3×240
95* 250QJ50-600/30 5474 483 160 2821 612 3×300
96* 250QJ50-620/31 5634 498 160 2821 612 3×300
97* 250QJ50-640/32 5794 513 160 2821 612 3×300
98* 250QJ50-660/33 5954 528 160 2821 612 3×400
90* 250QJ50-680/34 6114 543 160 2821 612 3×400
100 250QJ80-20/1 285 22.2 7.5 705 72 3×4
101 250QJ80-40/2 420 38.6 15 815 90 3×6
102 250QJ80-60/3 555 55 22 981 143.6 3×10
103 250QJ80-80/4 860 88.6 30 1036 160.6 3×16
104 250QJ80-100/5 995 105 37 1076 165.6 3×16
105 250QJ80-120/6 1130 121.4 45 1141 170.6 3×16
106 250QJ80-140/7 1265 137.8 55 1216 180.6 3×25
107 250QJ80-160/8 1400 154.2 55 1216 180.6 3×25
108 250QJ80-180/9 1535 170.6 63 1461 231 3×35
109 250QJ80-200/10 1670 187 75 1611 274 3×50
110* 250QJ80-220/11 1805 203.4 90 2159 310 3×70
112* 250QJ80-240/12 1940 219.8 90 2159 310 3×70
113* 250QJ80-260/13 2075 236.2 90 2159 310 2875 4 3×70 233
114* 250QJ80-280/14 2210 252.6 110 2349 345 3×95
115* 250QJ80-297/11 3060 269 110 2349 345 3×95
116* 250QJ80-324/12 3280 285.4 125 2561 597 3×120
117* 250QJ80-351/13 3500 301.8 125 2561 597 3×150
118* 250QJ80-378/14 3720 318.2 140 2731 602 3×150
119* 250QJ80-405/15 3940 334.6 160 2821 312 3×185
120* 250QJ80-432/16 4160 351 160 2821 312 3×240
121* 250QJ80-459/17 4380 367.4 185 2931 626 3×240
122* 250QJ80-486/18 4600 383.8 185 2931 626 3×240
123* 250QJ80-513/19 4820 400.2 220 3091 660 3×300
124* 250QJ80-540/20 5040 416.6 220 3091 660 3×300
125* 250QJ80-567/21 5260 433 220 3091 660 3×300
126* 250QJ80-594/22 5480 449.4 220 3091 660 3×300
127 250QJ100-18/1 285 20 7.5 705 72 3×4
128 250QJ100-36/2 420 35 15 815 90 3×6
129 250QJ100-54/3 555 50 25 1001 150.6 3×16
130 250QJ100-72/4 860 65 30 1036 160.6 3×16
131 250QJ100-90/5 995 98 45 1141 170.6 3×25
132 250QJ100-108/6 1130 117 45 1141 170.6 3×25
133 250QJ100-126/7 1365 136 55 1216 180.6 3×25
134 250QJ100-144/8 1400 155 63 1461 231 3×35
135 250QJ100-162/9 1535 174 75 1611 274 3×35
136* 250QJ100-180/10 1670 193 90 2159 310 3×50
137* 250QJ100-198/11 1805 212 90 2159 310 3×50
138* 250QJ100-216/12 1940 231 110 2349 345 3×70
139* 250QJ100-225/9 2400 250 110 2349 345 5 3×70
140* 250QJ100-250/10 2620 269 110 2349 345 3×95
141* 250QJ100-275/11 3060 288 125 2561 597 3×95
142* 250QJ100-300/12 3280 307 140 2731 602 3×120
143* 250QJ100-325/13 3500 326 160 2821 612 3×150
144* 250QJ100-350/14 3720 345 160 2821 612 3×185
145* 250QJ100-375/15 3940 364 185 2931 626 3×240
146* 250QJ100-400/16 4160 383 185 2931 626 3×240
147* 250QJ100-425/17 4380 402 220 3091 660 3×240
148* 250QJ100-450/18 4600 421 220 3091 660 3×240
149* 250QJ100-475/19 4820 440 220 3091 660 2875 5 3×240 233
150 250QJ125-16/1 315 29.4 9.2 750 79 3×4
151 250QJ125-32/2 480 44.4 18.5 961 135.6 3×6
152 250QJ125-48/3 645 59.4 25 1001 150.6 3×16
153 250QJ125-64/4 810 74.4 37 1076 165.6 3×16
154 250QJ125-80/5 1145 109 45 1141 170.6 3×16
155 250QJ125-96/6 1310 124 55 1216 180.6 3×25
156 250QJ125-112/7 1475 139 63 1461 231 3×35
157 250QJ125-128/8 1640 154 75 1611 274 3×35
158 250QJ125-144/9 1805 169 90 1731 299 3×50
159 250QJ125-160/10 1970 184 90 1731 299 3×50
160 250QJ125-176/11 2135 199 110 1921 324 3×70
161* 250QJ125-202/9 2400 214 110 2349 345 3×70
162* 250QJ125-225/10 2620 229 125 2561 597 3×95
163* 250QJ125-247/11 3060 244 140 2731 602 3×95
164* 250QJ125-270/12 3280 259 160 2821 612 3×120
165* 250QJ125-292/13 3500 274 160 2821 612 3×150
166* 250QJ125-315/14 3720 289 185 2931 626 3×185
167* 250QJ125-338/15 3940 304 185 2931 626 3×185
168* 250QJ125-360/16 4160 319 220 3091 660 3×240
169* 250QJ125-383/17 4380 334 220 3091 660 3×240
170 250QJ140-15/1 315 28 9.2 815 79 3×6
171 250QJ140-30/2 480 48 18.5 961 135.6 3×6
172 250QJ140-45/3 645 68 30 1036 160.6 3×16
173 250QJ140-60/4 810 88 37 1076 165.6 3×16
174 250QJ140-75/5 1145 108 45 1141 170.6 3×16
175 250QJ140-90/6 1310 128 55 1216 180.6 3×25
176 250QJ140-105/7 1475 148 63 1461 231 3×35
177 250QJ140-120/8 1640 168 75 1161 274 3×35
178 250QJ140-135/9 1805 188 90 1731 299 3×50
179 250QJ140-150/10 1970 208 90 1731 299 3×50
180* 250QJ140-165/11 2135 228 110 2349 345 3×50
181* 250QJ140-180/12 2300 248 110 2349 345 3×70
182* 250QJ140-189/9 2400 268 110 2349 345 3×70
183* 250QJ140-210/10 2620 288 125 2561 597 3×95
184* 250QJ140-231/11 3060 308 140 2731 602 3×95
185* 250QJ140-252/12 3280 328 160 2821 612 2875 5 3×120 233
186* 250QJ140-273/13 3500 348 185 2931 626 3×150
187* 250QJ140-294/14 3720 368 185 2931 626 3×185
188* 250QJ140-315/15 3940 388 220 3091 660 3×240
189* 250QJ140-336/16 4160 408 220 3091 660 3×240
190 250QJ150-20/1 420 52 15 815 90 3×6
191 250QJ150-40/2 640 70 30 1036 160.6 3×16
192 250QJ150-60/3 860 88 45 1141 170.6 3×25
193 250QJ150-80/4 1300 144 55 1216 180.6 3×25
194 250QJ150-100/5 1520 162 63 1461 231 3×35
195 250QJ150-120/6 1740 180 75 1611 274 3×35
196 250QJ150-140/7 1960 198 90 1731 299 3×50
197 250QJ150-160/8 2180 216 110 1921 324 3×50
198* 250QJ150-180/9 2400 234 125 2561 597 3×70
199* 250QJ150-200/10 2620 252 140 2731 602 3×95
200* 250QJ150-220/11 3060 270 160 2821 612 3×95
201* 250QJ150-240/12 3280 288 160 2821 612 3×120
202* 250QJ150-260/13 3500 306 185 2931 626 3×150
203* 250QJ150-280/14 3720 324 185 2931 626 3×150
204* 250QJ150-300/15 3940 342 220 3091 660 3×185
205 250QJ160-15/1 420 50 11 765 85 3×6
206 250QJ160-30/2 640 70 22 981 143.6 3×16
207 250QJ160-45/3 860 120 37 1076 165.6 3×25
208 250QJ160-60/4 1080 140 45 1141 170.6 3×25
209 250QJ160-75/5 1520 160 55 1216 180.6 3×25
210 250QJ160-18/1 420 180 13 780 87 3×6
211 250QJ160-36/2 640 200 25 1001 150.6 3×16
212 250QJ160-54/3 860 220 37 1076 165.6 3×16
213 250QJ160-72/4 1300 240 55 1216 180.6 3×25
214 250QJ160-90/5 1520 260 63 1461 231 3×35




Hot Tags: 10'' Cast Iron Deep Well Pump, China, Manufacturer, Supplier, Factory, Customized, Quality, Latest Sales, In Stock, Brands, CE, Taizhou

Related Category

Intelligent Frequency Converter Pump

Surface Pump

Garden Pump

Submersible Pump

Sewage Pump

Deep Well Pump

Solar Pump

Circulation Pump

Pipeline Pump

Commercial Centrifuge

Double Suction Pump

End Suction Pump

Pool and Spa Pump

Pumping pump

Engine Pump

Emergency Trailer Drain Pump and Diesel Engine Pump

Send Inquiry

Please Feel free to give your inquiry in the form below. We will reply you in 24 hours.

Related Products

X
We use cookies to offer you a better browsing experience, analyze site traffic and personalize content. By using this site, you agree to our use of cookies. Privacy Policy
Reject Accept
